Details
| Category | Extrusion lines |
|---|---|
| Kind | Blownfilm lines co-ex |
| Brand | eurexma |
| Model | K2A |
| Year | 2016 |
| Layers (nr) | 2 |
| Material | LDPE |
| Extruders (pieces) | 2 |
| Screw (a/b/c) (mm) | 40 |
| Screw L/D (a,b,c) | 30 |
| Motor (kW) | 2x11 |
| Die (1=fix 2=oscilating 3=rotating) | 1 |
| Head diameter (mm) | 100 |
| Die gap min-max (mm) | |
| IBC (int.cooling) (0=no 1=yes) | |
| Airring (0=no 1=yes) | |
| Filmthickness (min-max) (µm) | |
| Thicknescontroll (0=no 1=yes) | |
| Nip Width (mm) | |
| Winder width BFLC | |
| Film width layflat max(mm) | 1000 |
| Corona (0=no 1=yes) | 0 |
| Tower included (0=no 1=yes) | 1 |
| Output (kg/hr) | 80 |
| Notes | line used to pilot project only. Like new. |
- Images:
-
-
